WOODBRIDGE 5 SLIMLINE

British-designed 4.9kW wood burning stove with a slim 295mm body, ideal for fireplaces where installation depth is limited.

The Woodbridge 5 Slimline has been developed for homeowners who want the performance of a full-sized wood burning stove where installation space is limited. Designed around the same proven combustion system as the standard Woodbridge 5 Deepline, the Slimline delivers the same outstanding performance in a shallower body, making it ideal for modern homes, new-build properties and false chimney breast installations.​ With a body depth of just 295mm, the Woodbridge 5 Slimline fits comfortably into fireplaces where a standard depth stove may not be suitable, without compromising on heat output, efficiency or flame picture.​



Delivering a 5kW nominal heat output, the generous firebox accommodates three to four standard logs or two logs up to 400mm in length, allowing longer burn times and fewer refuelling stops. The large panoramic viewing window, shared with the standard Woodbridge 5, creates an impressive focal point and offers an exceptional view of the dancing flames.​



Built with ease of use in mind, the Woodbridge 5 Slimline features a smooth air control system, a cool-touch handle and an optional drop-in multifuel kit, providing the flexibility to burn either seasoned wood or approved smokeless fuels.

KEY FEATURES

✔ Slim 295mm Body Depth
Designed for tight chimney breasts, shallow alcoves and modern media-wall installations.
✔ 5kW Nominal Output (2–7kW Range)
Ideal for small to medium rooms, with controllable heat output.
✔ Panoramic Viewing Window
Generous glass area provides an excellent view of the flames.
✔ Smooth Air Control System
Single-lever control for easy combustion adjustment.
✔ Cool‑Touch Handle
Safe and comfortable for everyday use.

✔ Optional Drop‑In Multifuel Kit

Converts the Slimline for use with approved smokeless fuels.

✔ 400mm Log Length Capacity

Accommodates longer logs for fewer refuelling stops.

✔ High Efficiency — 82.2% (Wood)

A+ rated with excellent clean-burn performance.

✔ EN16510 Tested (Latest Standard)

Tested to the latest European stove standard.

✔ Designed & Made in Suffolk, UK

Built locally with Pevex craftsmanship.

Woodbridge 5 Slimline spec

SPECIFICATIONS

Specification
Woodbridge 5 Slimline
Width x Depth x Height (mm)
505 x 367 x 540
Weight (kg)
75
Log Length (mm)
400
Flue dia. (mm) outlet & position
125 top/rear
Nominal output (kW)
4.9
Output Range (kW)
2-7
Distance from rear of stove to centre of top flue outlet (mm)
126
Rear with twin wall flue (mm)
200
From sides (mm)
400
Above (mm)
300
From front (mm)
1100
Approx. Heating area (m²)
20-115
Efficiency (net): Wood
82.2%
OGC @ 13% O₂ (mg/Nm³)
42
CO% @ 13% O₂: Wood
0.05
Particulates @ 13% O₂ (mg/Nm³)
14
NOx @ 13% O₂ (mg/Nm³)
127
Test standard
EN 16510-1
Ecodesign
✓

WOODBRIDGE 5 SLIMLINE DRAWING

Woodbridge 5 Slim Dims.png

WOODBRIDGE 5 SLIMLINE - DISTANCE TO COMBUSTIBLES

Woodbridge 5 - Distance to combustibles.png

WOODBRIDGE ACCESSORIES

Solid Fuel Handle
Solid Fuel air control lever
Woodbridge 5 Slimline Burning

WOODBRIDGE 5 SLIMLINE LIVE BURNING

Live Demo

Highly Controllable

DOWNLOADS AND TECHNICAL INFORMATION

TRUSTED BRITISH DESIGN AND MANUFACTURE

British Made

BRITISH
MADE

Ecodesign Compliant

ECODESIGN
COMPLIANT

A+ Energy Rating

A+ ENERGY RATING

EN16510 Tested

EN16510 TESTED
