BRIGHTWELL DOUBLE SIDED WOOD BURNING STOVE
BRIGHTWELL 900 DOUBLE SIDED
BRIGHTWELL 900 DOUBLE SIDED WOOD BURNING STOVE
The Brightwell 900 Double Sided is a British-made 9kW double-sided wood burning stove, designed to provide warmth and an impressive view of the flames from two adjoining rooms. Ideal for open-plan living spaces and fireplace openings between rooms, this substantial stove combines large viewing windows on both sides with robust steel and cast-iron construction. With a generous 400mm log capacity and a 4–12kW output range, the Brightwell 900 delivers powerful heating performance while creating a striking focal point in the home.

Nominal output

Output range

Efficiency

Energy rating

Body depth

Log length
Brightwell 900 Double Sided
The Brightwell 900 Double Sided is a powerful 9kW Ecodesign stove engineered for open‑plan living and dual‑room installations. With an impressive 79% efficiency and a wide 4–12kW heat range, it delivers generous warmth to both sides of a dividing fireplace, creating a dramatic centrepiece that can be enjoyed from two rooms at once.
Modern, unfussy lines and twin cast‑iron doors provide clear, uninterrupted views of the flames, allowing you to appreciate the fire burning brightly and lazily within the chamber. The convector top plate and heavy‑duty steel body ensure long‑lasting durability, while the push‑pull air controls beneath each door offer smooth, precise adjustment of primary and secondary air. This keeps the glass clear on both sides and helps you achieve the perfect balance of comfort, harmony and efficient combustion.
For added presence, the Brightwell 900 can be elevated with an optional 200mm or 300mm logstore, raising the stove for easier loading and an enhanced view of the fire. Homes requiring an external air supply can also benefit from a dedicated Fresh Air adaptor, available separately — an important addition for modern airtight properties.
Features
✓ 9kW Nominal Heat Output
Powerful heat output suited to larger rooms and open-plan living spaces.
✓ 79% Efficiency
Efficient combustion delivers strong heating performance.
✓ 400mm Log Length
Generous firebox accommodates logs up to 400mm in length.
✓ Cast Iron Doors
Robust construction provides durability and a quality finish.
✓ Heavy-Duty Steel Construction
Built with a 5mm steel body and substantial 12mm steel top plate.
✓ Twin Cast Iron Grates
Two robust grates provide effective fuel support across the firebox.
✓ Independent Air
ControlsSimple air sliders control primary and secondary air for precise combustion.
✓ Airwash System
Helps maintain a clear view of the fire through the glass on both sides.
✓ Convector Top PlateDesigned to enhance the circulation of heat into the room.
✓ Ecodesign Compliant
Designed to meet modern efficiency and emissions requirements.
✓ A Energy Rating
Rated A for energy efficiency.
SPECIFICATIONS
Specification | Brightwell 900 Double Sided |
|---|---|
Width x depth x height (mm) | 542 x 542 x 618 |
Weight (kg) | 155 |
Log length (mm) | 400 |
Flue dia. (mm) outlet & position | 155 Top |
Nominal output (kW) | 9 |
Range rating (kW) | 4-12 |
Distance from rear of stove to centre of top flue outlet (mm) | 281 |
Distance to flammable materials: | |
From sides (mm) | 580 |
From door front (mm) | 1050 |
Heating area (m²) | 20-180 |
Efficiency (net): Wood | 79% |
OGC@ 13% O2 | 83 |
CO% @ 13% O2: Wood | 0.09 |
Particulates mg/NM3 | 24 |
Certified | UKCA |
Ecodesign | ✓ |
Defra approved | Tested to |
DOWNLOADS AND TECHNICAL INFORMATION
TRUSTED BRITISH DESIGN AND MANUFACTURE

BRITISH
MADE



ECODESIGN
COMPLIANT
A ENERGY RATING
DEFRA EXEMPTION PENDING
